TCN4H 48X96mm Temperature Controller
Input signal: Multi Sensor (K,E,J,Pt100,Cu50) Editable input signal
OUTPUT: Relay output: Contact capacity 250VAC
- Brand
- NQQK
TCN4H 48X96mm Temperature Controller
Product Description：
Main technical parameters:
Input signal: Multi Sensor (K,E,J,Pt100,Cu50)
Editable input signal
OUTPUT: Relay output: Contact capacity 250VAC 10A(resistive),resistive heating can directly load 1000W.
Voltageplus output:DC0~12V( suitable for SSR)
Alarm function output: NO/OFF, 250VAC 10A (resistive), one output with 4 type
Control mode: PlD adjustment with contact output break-make NO/OFF
Work power:AC/DC85-264V±10%, 50HZ-60HZ
Feature:
1,dual output : relay+SSR, More flexible use
2,Power on self-tuning for more precise temperature control
3,Simplify the menu settings and make operations more convenient
Measureing Range:
| Enter the graduation number of the sensor | Display measuring range | ||||
| K | 0~1300℃ | ||||
| J | 0~800℃ | ||||
| E | 0~800℃ | ||||
| Pt100 | -199.9~+649.0℃ | ||||
| Cu500 | -50~+150℃ |
